HP 17 Laptop - Complete DIY Disassembly & Upgrade Guide: RAM, SSD, Battery, LCD & Motherboard Replacement
Jul 11, 2025
Pre-Disassembly: Value Assessment Bottom Cover Removal RAM Upgrade & Resale SSD Replacement Battery Removal LCD Screen Guide Motherboard Value Selling HP Parts
1. HP 17 Laptop Pre-Disassembly: Maximize Your Part-Out Profit
1. Component Valuation Guide (Q3 2024)
Part
Condition
Price Range
HP Premium
8GB DDR4 RAM
Working, tested
$18-$28
+10%
256GB NVMe SSD
Health >85%
$22-$38
+15%
41Wh Battery
<300 cycles
$35-$55
+20%
2. Essential Documentation
Performance Records :
Run HP Hardware Diagnostics
Capture battery health (F2 at boot)
Visual Evidence :
Photograph Product ID and Serial Number
Record HP part numbers (e.g., L05757-005)
Show no physical damage
4. Safety Precautions
Disconnect AC adapter
Hold power button 10 seconds to discharge
Remove all peripherals
5. Pre-Sale Optimization
Data Security :
Perform HP Secure Erase
Remove BIOS passwords
For Refurbishers :
Resale Secret: HP components with complete documentation sell for 20-30% more on HP's official refurbished marketplace.
2. HP 17 Laptop Bottom Cover Removal: Safe Access for Upgrades
1. Screw Removal Process
Locate All Fasteners :
12 captive Phillips screws (marked with keyboard icons)
Use magnetic mat to prevent loss
Proper Technique :
Apply firm downward pressure (0.5 Nm torque)
HP-specific: Screws remain in cover when loosened
2. Cover Release Points
Area
Release Method
Tool
Front Edge
Start near touchpad corners
Plastic spudger
Rear Edge
Lift upward at 20° angle
iFixit opening picks
3. Preserving Resale Value
No-Scratch Technique :
Plastic tools only (metal voids HP warranty)
Damaged clips reduce value by 15-25%
Reassembly Prep :
Note screw positions (different lengths)
Check rubber foot alignment
4. Common HP-Specific Issues
Problem
Solution
Resale Impact
Stuck clips
Guitar pick method
None if done properly
Stripped screw
Rubber band grip trick
5-10% value loss
5. Model-Specific Notes
17-cn0000 series has stronger clips than 17-cp0000
No hidden screws under rubber feet
Ventilation grilles are fragile - handle carefully
Resale Tip: Undamaged HP covers with all original screws sell for 10-15% more to refurbishers. Document with timestamped photos.
VIDEO
0:21 Bottom Case 0:36 DVD Optical Drive 1:42 Battery 2:23 Memory RAM 2:48 Heatsink 3:18 Cooling Fan 3:43 WiFi Card 4:10 Unscrew all Motherboard Screws 5:43 Motherboard 6:18 IO USB Board 6:42 Speakers 7:08 Hinges 7:38 DC Power Jack 7:52 Palmrest Assembly 7:56 Keyboard 8:02 Touchpad 8:16 Display Assembly
3. HP 17 Laptop RAM Upgrade: Performance Boost & Resale Value
1. RAM Specifications
Slots
Type
Max Capacity
Speed
Part Number
2x SODIMM
DDR4
32GB (16GBx2)
3200MHz
L05757-005
2. RAM Replacement Process
Access Slots :
Remove bottom cover (see Section 2 )
Locate RAM slots near cooling fan
Installation :
Release side clips simultaneously
Insert at 30° angle (gold contacts first)
Press down until audible click
3. Current Resale Values (Q3 2024)
Capacity
Used OEM
New Retail
HP Premium
4GB DDR4
$12-$20
$25-$40
+5%
8GB DDR4
$20-$35
$45-$70
+10%
16GB DDR4
$40-$65
$80-$120
+15%
4. Pre-Sale Testing
Diagnostics :
Run MemTest86 for 2+ passes
Verify in Windows Task Manager
Documentation :
5. Maximizing Resale Value
For Individual Buyers :
Clean contacts with isopropyl alcohol
Include original capacity stickers
For Refurbishers :
Keep matched pairs together
Provide HP service tag compatibility
Resale Secret: 16GB RAM kits from HP laptops sell for 25-35% premiums when marketed as "Tested OEM Pulls" with diagnostic reports.
4. HP 17 Laptop SSD Upgrade: Storage Solutions & Resale Profits
1. SSD Specifications
Slot Type
Form Factor
Interface
Max Capacity
Part Number
Primary
M.2 2280
PCIe Gen3 x4 NVMe
2TB
L05757-005
2. SSD Replacement Process
Locate SSD Bay :
Remove single M2x3 screw (marked with storage icon)
Note thermal pad orientation (if present)
Install New SSD :
Insert at 30° angle (gold contacts first)
Apply 0.6 Nm torque to retention screw
Reattach any thermal shielding
3. Current Resale Values (Q3 2024)
Capacity
Used OEM
New Retail
HP Premium
256GB NVMe
$25-$40
$50-$80
+10%
512GB NVMe
$40-$65
$85-$130
+15%
1TB NVMe
$70-$110
$140-$200
+20%
4. Pre-Sale Data Sanitization
Secure Erase :
Use HP Secure Erase in BIOS
Or boot to DBAN for advanced wiping
Health Verification :
5. Maximizing SSD Value
For Individual Buyers :
Include original mounting hardware
Show power-on hours under 8,000
For Refurbishers :
Provide certificate of data destruction
Note HP service tag compatibility
Resale Secret: SSDs with documented health reports and HP OEM markings sell for 30-40% more when marketed as "Certified Pulls" with wipe verification.
5. HP 17 Laptop Battery Removal: Safe Extraction & Resale Guide
1. Battery Specifications
Type
Capacity
Voltage
Part Number
Cycle Life
Li-ion
41Wh/55Wh
11.4V
L05757-005
500 cycles
2. Safe Removal Process
Power Down :
Shut down completely
Hold power button for 15 seconds
Disconnect Battery :
Locate 4-pin connector (center-right)
Use plastic spudger to release latch
Remove Battery :
Unscrew 4x Phillips #00 screws
Lift from bottom edge at 25° angle
3. Current Resale Values (Q3 2024)
Condition
41Wh Battery
55Wh Battery
New OEM
$50-$75
$70-$95
<200 cycles
$35-$55
$50-$75
<400 cycles
$25-$40
$35-$55
4. Battery Health Documentation
Generate Reports :
Run powercfg /batteryreport in Command Prompt
Capture HP Battery Check results
Key Metrics :
Cycle count under 300
Design capacity above 80%
No swelling or damage
5. Safe Shipping & Compliance
Preparation :
Discharge to 30-50% capacity
Protect terminals with non-conductive tape
Regulations :
6. Maximizing Resale Value
For Individual Buyers :
Include original capacity sticker
Show charge cycles in listing
For Refurbishers :
Provide HP service tag compatibility
Include remaining warranty documentation
Resale Secret: Batteries with under 200 cycles and HP OEM markings sell for 30-40% premiums when marketed with health reports and original packaging.
6. HP 17 Laptop LCD Replacement: Display Options & Resale Strategy
1. Compatible Display Panels
Model
Resolution
Type
Part Number
Touch
Standard
1600×900 (HD+)
TN
L05757-005
No
Premium
1920×1080 (FHD)
IPS
L12345-001
No
2. Safe Screen Replacement
Bezel Removal :
Use plastic pry tool starting at bottom edge
Release 8 clips (4 top, 4 bottom)
Note adhesive strip locations
Display Disconnection :
Release 40-pin eDP connector latch
Remove webcam cable carefully
New Panel Installation :
Align with mounting holes (4x M2.5 screws)
Torque to 0.4 Nm (HP specification)
3. Current Resale Values (Q3 2024)
Panel Type
Used/Tested
New OEM
HP Premium
HD+ TN
$40-$70
$90-$140
+10%
FHD IPS
$80-$120
$150-$220
+20%
4. Selling Your Old Screen
Condition Documentation :
Photograph with >HP Display Test
Note dead pixels (under 3 is Grade A)
Show backlight uniformity
Packaging :
Use original protective foam
Double-box with 2" padding
5. Common HP-Specific Issues
Problem
Solution
Resale Impact
Minor backlight bleed
Market as "B-Stock"
15% reduction
1-2 dead pixels
Disclose clearly
10% reduction
6. HP 17-Specific Notes
No touchscreen option available
Bezel adhesive is reusable 2-3 times
Webcam cable is fragile - handle with care
Resale Tip: Screens with matching HP part numbers and under 1,000 power-on hours sell for 25-35% premiums when marketed with test pattern photos and original packaging.
7. HP 17 Laptop Motherboard Resale: Maximizing Your Return
1. Motherboard Specifications
Chipset
CPU Support
Part Number
Warranty Status
Intel H-series/AMD Promontory
10th/11th Gen Intel or Ryzen 5000
L05757-005
Transferable
2. Current Resale Values (Q3 2024)
Configuration
Fully Functional
For Parts/Repair
Intel i5-1035G1
$150-$220
$80-$120
Ryzen 5 5500U
$180-$250
$100-$150
Intel i7-1165G7
$220-$300
$130-$180
3. Pre-Sale Preparation
BIOS Reset :
Clear all passwords
Disable Computrace
Restore factory settings
Documentation :
Photograph all HP service tags
Include HP Diagnostics results
Show CPU stress test (Prime95)
4. Target Buyer Markets
Repair Shops :
Seek donor boards for specific components
Value partial functionality
Refurbishers :
Require complete service history
Pay premium for tested boards
5. Safe Shipping Practices
Use anti-static bag + 2" foam padding
Remove CMOS battery
Include screw inventory list
6. Compatibility Notes
Only works with HP 17 chassis
Requires matching generation CPU/RAM
Not compatible with 17t models
Enterprise Tip: Motherboards with intact service tags and under 1 year of remaining warranty sell for 40-50% premiums through HP's certified refurbishment channels.
8. Selling HP 17 Laptop Parts: Best Marketplaces & Strategies
1. Top Platforms for HP Components
2. Selling to Institutions
.gov Requirements :
.edu Preferences :
Complete asset tags
5+ unit lots preferred
Classroom-ready configurations
3. SEO-Optimized Listing Strategies
Platform
Title Formula
Keywords
SellBroke
"HP 17 [Part] [PN] - Tested Working"
OEM, Pulled, Grade A
.gov
"HP 17 Laptop [NSN] [Part#] - GSA Eligible"
FSC, TAA Compliant
.edu
"HP 17 [Part] - EDU Discount Available"
Campus, Lab Ready
4. Best Selling Times
Government : August-September (FY end)Education : May-July (summer upgrades)Consumer : November-December (holiday demand)
5. Common Value Killers
Mistake
Solution
Value Impact
Missing service tags
Photograph before disassembly
40% reduction
No test reports
Include HP Diagnostics results
30% lower offers
Enterprise Secret: Lots of 3+ matching HP components qualify for HP Certified Refurbished program, increasing value by 35-50% with warranty options.
