MSI Modern 14 B10MW Laptop - Complete Disassembly & Upgrade Guide: RAM, SSD, Battery, LCD & Motherboard Replacement
Pre-Disassembly Valuation & Tools Bottom Case Removal Process RAM Upgrade & Current Market Prices SSD Replacement & Resale Value Battery Removal & Selling Strategies LCD Screen Replacement Guide Motherboard Resale Potential Where to Sell MSI Laptop Parts
1. MSI Modern 14 B10MW Pre-Disassembly: Value Assessment & Preparation
1. Component Valuation Guide
Part
Condition
Price Range
16GB DDR4 RAM
Used, tested
$35-$55
512GB NVMe SSD
Low hours
$40-$70
Original Battery
<300 cycles
$60-$100
2. Resale Documentation
Performance Records :
Run MSI Hardware Diagnostics
Capture battery health (Del at startup)
Visual Documentation :
Photograph serial numbers and condition
Record MSI part numbers (e.g. MS-12345)
4. Warranty Verification
Check MSI Warranty Status
Review MSI's upgrade policy
Note remaining coverage period
5. Safety Precautions
Power down and unplug charger
Discharge residual power (hold power button 15 sec)
Use anti-static wrist strap
Resale Tip : Documenting your upgrade process with FTC-compliant records increases buyer trust and resale value by 25-30% for MSI components.
2. MSI Modern 14 B10MW Bottom Case Removal: Safe Access for Upgrades
1. Screw Removal Protocol
Locate All Fasteners :
8 captive screws (4 long near hinges, 4 short)
Use magnetic mat to organize
Proper Technique :
PH00 screwdriver with 0.6 Nm torque
MSI-specific screw pattern (follow service manual)
2. Hidden Clip Locations
Area
Release Method
Tool
Front Edge
Insert at 30° angle near touchpad
0.5mm plastic spudger
Vent Areas
Slide horizontally toward rear
iFixit opening picks
3. Safe Case Separation
Initial Break :
Start near hinge area (MSI weak point)
Use suction cup for initial lift
Full Removal :
Maintain 25° angle during separation
Watch for keyboard ribbon cable (center-right)
4. Preserving Resale Value
No-Scratch Technique :
Plastic tools only (metal voids MSI warranty)
Damaged cases reduce value by 20-25%
Reassembly Prep :
Photograph screw locations
Note clip positions for perfect reattachment
Common MSI-Specific Issues
Problem
Solution
Resale Impact
Stuck clip
Apply 99% isopropyl with brush
Prevents case warping
Stripped screw
Use rubber band for grip
Avoids service marks
Resale Tip : Undamaged cases with all original screws sell for 30% higher prices on MSI refurbishment markets.
VIDEO
0:20 Bottom Case 1:40 Battery 2:30 SSD storage 2:50 WiFi card 3:21 Memory RAM 3:40 Heatsink Cooling Fan 4:28 Disconnect all cables 6:53 Motherboard 7:25 Hinges 7:58 Palmrest, Keyboard assembly 8:05 Touchpad 8:45 Speakers 9:03 Display LCD Assembly
3. MSI Modern 14 B10MW RAM Upgrade: Performance Boost & Resale Value
RAM Specifications
Model
Type
Speed
Capacity
Channels
Stock Configuration
DDR4 SODIMM
3200MHz
8GB (1x8GB)
Single
Upgrade Potential
DDR4 SODIMM
3200MHz
64GB Max (2x32GB)
Dual
RAM Installation Process
Access RAM Slots :
Located under metal shield (2 screws)
Remove shield carefully to avoid bending
Module Replacement :
Press outward on retention clips (45° angle)
Insert new RAM at 30° angle
Press down firmly until audible click
Current Resale Values (Q3 2024)
Configuration
Condition
Price Range
MSI Premium
8GB DDR4-3200
Used, tested
$25-$40
+15%
16GB DDR4-3200
Like new
$45-$70
+20%
32GB DDR4-3200 Kit
New sealed
$120-$180
+25%
Maximizing Resale Value
Cleaning & Preparation :
Gently clean contacts with 99% isopropyl alcohol
Remove all dust from heat spreaders
Documentation :
Run MemTest86 for 4+ hours
Include screenshots of test results
Buyer Compatibility Notes
Works with MSI Modern/Prestige 2020-2023 models
Verify BIOS supports 32GB modules
Not compatible with MSI AMD Ryzen models
Valuation Tip : RAM kits with matching MSI part numbers sell 30% faster than generic listings. Document part# MS-4F32G320C22 for maximum value.
4. MSI Modern 14 B10MW SSD Upgrade: Storage Solutions & Resale Value
SSD Compatibility
Slot Type
Form Factor
Interface
Max Capacity
Speed
Primary
M.2 2280
NVMe PCIe 3.0 x4
2TB
3500MB/s
Secondary
M.2 2242
SATA III
1TB
550MB/s
SSD Replacement Process
Primary NVMe Installation :
Remove single M2x3 screw
Insert SSD at 30° angle (gold contacts first)
Secure with 0.6 Nm torque
Secondary SATA Installation :
Use M.2 2242 adapter if needed
Secure with included bracket
Current SSD Values (Q3 2024)
Capacity
Used OEM
New Retail
MSI Premium
256GB NVMe
$25-$40
$45-$65
+20%
512GB NVMe
$40-$70
$75-$110
+25%
1TB NVMe
$80-$130
$140-$190
+30%
Maximizing Resale Value
Data Sanitization :
Use MSI Secure Erase in BIOS
Include wipe certification
Health Reporting :
Document TBW under 50% rating
Show power-on hours under 5,000
Buyer Compatibility Notes
Works with MSI Modern/Prestige 2019-2023 models
Not compatible with PCIe 4.0/5.0 drives
2242 slot requires specific bracket
Resale Tip : SSDs with documented low power-on hours (under 2,000) and original MSI stickers sell for 35-40% premiums in refurb markets. Always include CrystalDiskInfo reports.
5. MSI Modern 14 B10MW Battery Replacement & Resale Guide
Battery Specifications
Model
Capacity
Voltage
Part Number
Cycle Life
Standard
52Wh
11.4V
BTY-M4D
500 cycles
Extended
72Wh
11.4V
BTY-M4X
800 cycles
Safe Battery Removal Process
Power Down Safely :
Shut down completely
Hold power button for 20 seconds (MSI specific)
Disconnect Battery :
Locate 3-pin white connector (center-left)
Use plastic spudger to release latch
Remove Battery :
Unscrew 4x T5 screws (marked ⚡)
Lift from bottom edge first
Current Resale Values (Q3 2024)
Condition
52Wh Battery
72Wh Battery
MSI Premium
New OEM
$90-$130
$120-$170
+35%
<200 cycles
$70-$100
$90-$140
+25%
<400 cycles
$50-$80
$70-$110
+15%
Maximizing Battery Value
Health Documentation :
Generate report via powercfg /batteryreport
Show cycle count under 300
Include MSI Battery Health screenshots
Physical Preparation :
Clean contacts with 99% isopropyl alcohol
Measure thickness (should be <8.5mm)
Shipping Compliance :
Discharge to 30-50% charge
Use FAA-compliant packaging
Include MSI safety documentation
Buyer Compatibility Notes
Fits MSI Modern 14 2020-2023 models
Verify BIOS version for 72Wh support
Not compatible with MSI Prestige series
Selling Tip : Batteries with documented MSI Battery Health over 90% sell 50% faster than untested units. Include original purchase date if available.
6. MSI Modern 14 B10MW LCD Replacement: Panel Options & Resale Value
Display Specifications
Model
Resolution
Panel Type
Refresh Rate
Part Number
Standard
1920×1080
IPS
60Hz
MS-14FHD-01
Upgrade Option
1920×1080
IPS-Level
144Hz
MS-14FHD-144
Screen Replacement Process
Bezel Removal :
Use plastic pry tools
Start at bottom edge (14 clips total)
MSI-specific clip locations marked with arrows
Display Disconnection :
Release 40-pin eDP connector latch
Remove webcam/mic cables (left side)
New Panel Installation :
Align with mounting holes (4x M2.5 screws)
Torque to 0.4 Nm (MSI spec)
Current Market Values (Q3 2024)
Panel Type
Used/Tested
New OEM
Refurb Premium
FHD IPS 60Hz
$80-$120
$150-$220
+25%
FHD 144Hz
$130-$180
$250-$350
+40%
Selling Your Old Screen
Condition Documentation :
Photograph with color test patterns
Note any dead pixels or backlight bleed
Include MSI panel ID sticker photos
Packaging :
Use original protective foam
Double-box with 2" padding
Mark as "Fragile - LCD Panel"
Common MSI-Specific Issues
Symptom
Solution
Resale Impact
Flickering
Reseat eDP cable
No value loss if fixed
3 dead pixels
Sell as "B-grade"
30% value reduction
Resale Tip : Screens with documented MSI FRU numbers sell 35% faster in refurb markets. Always include panel model# from the back sticker.
7. MSI Modern 14 B10MW Motherboard: Resale Valuation & Market Demand
Motherboard Specifications
Model
Chipset
CPU Support
Part Number
Production Year
MS-14J9
Intel HM470
10th Gen Comet Lake
MB-14J9-01
2020-2022
Current Resale Values (Q3 2024)
Condition
i5-10210U
i7-10510U
Parts/Repair
Fully Functional
$180-$250
$250-$350
-
Minor Issues
$120-$180
$180-$250
$80-$150
For Parts Only
$60-$120
$100-$180
$50-$100
Maximizing Resale Value
Documentation :
Photograph all MSI serial numbers
Include BIOS version screenshots
Show CPU stress test results
Presentation :
Target Buyer Markets
Refurbishers :
Pay 20-30% premium for working boards
Require complete documentation
Repair Shops :
Seek boards with known-good components
Value partial functionality
Hobbyists :
Look for project boards
Accept minor defects
Compatibility Notes
Works with MSI Modern 14 B10MW/B11MW
Not compatible with 11th Gen CPUs
Requires specific cooling solution
Resale Tip : Motherboards with intact MSI warranty stickers and unmodified BIOS sell for 40-50% higher prices to professional refurbishers.
8. Best Platforms to Sell MSI Modern 14 B10MW Parts for Maximum Profit
Top Online Selling Platforms
Platform
Best For
Fees
Payout Speed
SellBroke Quick corporate buybacks
No listing fees
3-5 business days
SellLaptopBack Individual part sales
12% commission
5-7 days
eBay Rare components
13.25% + $0.30
2-4 days
Government & Education Channels
.gov Auctions :
GovDeals - Bulk IT equipment10% buyer premium + 5% seller fee
Ideal for 5+ units
.edu Surplus :
PublicSurplus - University resale
7% base fee + 3% payment processing
Great for tested components
MSI-Specific Options
MSI Authorized Refurbishers :
Require MSI Renew certification
Pay 15-20% above market for certified parts
Local Repair Shops :
Offer quick cash for working components
Typically pay 70-80% of market value
MSI Part Pricing Strategy
OEM Premium :
Genuine MSI parts: +25-35% value
Include FRU numbers (e.g., MS-14J9-01)
Bundling :
Motherboard+CPU+RAM combos sell faster
Complete display assemblies preferred
MSI Component Shipping Guide
Component
Packaging
Carrier
Insurance
Motherboard
Anti-static bag + 2" foam
FedEx Ground
Full value
LCD Panel
Original foam + double box
UPS Fragile
+20% value
Tax Tip : Document all sales for IRS Form 1099-K when exceeding $600/year on platforms like SellLaptopBack or eBay. MSI parts sales are considered business income.
